Kia EV6: Electric vehicle guide / V2L has ended. Battery level has reached the set value

Never touch the Kia EV6 V2L connector or charging outlet while damaged or contaminated.

Do not insert metal objects into the V2L connector or charging port, as this may cause electric shock, fire, or severe injury.

Never touch the V2L connector, charging outlet, or power plug with wet hands. Always handle Kia EV6 charging equipment using completely dry hands to reduce the risk of electric shock.

Before connecting the Kia EV6 V2L system, confirm that there is no water, dirt, dust, or foreign material inside the charging outlet, V2L connector, or power plug. Foreign substances may cause electrical shock or fire.

Do not modify, disassemble, or alter the Kia EV6 V2L connector. Unauthorized modifications may increase the risk of fire, electrical shock, or injury.

Using the Kia EV6 V2L system under the following conditions may result in injury or equipment damage:

• The V2L connector, charging outlet, charging cable, or power plug is damaged, corroded, cracked, or rusted.

• The electrical connection is loose or unstable.

Do not operate damaged electrical appliances using the Kia EV6 V2L system, as damaged equipment may cause fire, electrical shock, or injury.

Never use high-heat electrical appliances such as irons, coffee makers, heaters, or toasters inside the Kia EV6 because these devices may cause overheating, fire, or injury.

To reduce the risk of accidents or damage, always read and follow the Kia EV6 owner’s manual before using the V2L system.

The Kia EV6 V2L discharge mode automatically stops if overheating is detected. If this occurs, inspect the V2L connector, power plug, and connected appliances for contamination, wear, corrosion, damage, or excessive electrical load. Once temperatures return to normal, V2L operation may resume.

Do not modify or disassemble the Kia EV6 V2L connector. Damage caused by unauthorized modification is not covered under the vehicle warranty.

Avoid dropping, striking, or placing heavy objects on the V2L connector.

Always disconnect the Kia EV6 V2L connector after completing V2L operation.

When the high-voltage battery reaches the configured discharge limit, V2L automatically stops operating and a warning message appears on the instrument cluster.

If multiple electronic devices are connected simultaneously to the Kia EV6 V2L system, ensure the combined power consumption does not exceed the maximum supported output.

Some appliances may not function correctly even when their power requirements remain below the maximum Kia EV6 V2L output capacity.

• Devices that require high startup current during initial operation.

• Precision measuring equipment that requires highly stable electrical output.

• Electronic devices sensitive to inverter-generated AC power.

Do not use medical equipment or devices requiring uninterrupted power supply through the Kia EV6 V2L system, since electrical output may be interrupted depending on vehicle conditions.

Only use electronic devices rated below 16A.

Fully extend all extension cords and use only compatible grounded plugs. Damaged or incompatible plugs may cause malfunction or overheating.

Do not use high-power household appliances such as washing machines, dryers, or large air conditioners with the Kia EV6 V2L system.

Do not hang heavy items from power cords or extension cables connected to the Kia EV6.

If multiple appliances are connected, use only certified electrical products that comply with national safety standards.

When operating outdoor equipment, always use waterproof products and avoid using the Kia EV6 V2L system in rain, standing water, or high-humidity environments.

Do not operate the Kia EV6 V2L system outdoors during thunderstorms or when lightning risk is present.

Do not connect multiple portable multi-outlets or use twisted extension cords, as they may overheat and create a fire hazard.

When using the exterior Kia EV6 V2L connector, electrical power is also supplied to the interior outlet. Disconnect any unused electronic devices from the interior power outlet.

While the Kia EV6 V2L system is operating, the cooling fan in the motor compartment may activate automatically even when the vehicle is turned OFF. Keep hands and objects away from the cooling fan area.

Connect the Kia EV6 V2L connector to the charging port within approximately 60 seconds after opening the charging door. Once connected, the system automatically locks the connector to help prevent theft.

When using the Kia EV6 V2L system, disable scheduled climate control settings because scheduled climate activation may interrupt V2L operation.

If the Kia EV6 is switched OFF while the interior V2L outlet is in use, V2L discharge mode automatically turns OFF.

If a connected electronic device fails to operate while the green indicator light is illuminated, disconnect the device and reconnect it again.

The Kia EV6 V2L discharge mode automatically turns OFF if the charging door is opened or the exterior V2L connector is connected. If using both interior and exterior V2L functions simultaneously, activate the interior V2L outlet first.
